GENUINE YUNNEI POWER 4100QBZL-22-H003 AIR COMPRESSOR HA22155 HA22073 4100QBZL-22-H002 HA2205 FOR YN4EL120-30CR DIESEL ENGINE

增压器总成 Turbocharger
1 4110004049027 增压器JYAC00-1118100-502 Turbocharger 1
2 4110003445135 垫片G3D00-1118201 Gasket 1
3 4110003445136 增压器进油接头475D-1118211A Hose assembly                     Y      1
4 4110000561258 法兰面螺栓 M8×20 Q1840820TF2 Screw 2
5 4110003445137 涡壳隔热罩J42MB-1118503 Heat insulation 1
6 4110003445138 螺母K6000-1008206 Nut 4
7 4110000009028 双头螺柱150-1118001 Stud 4
8 4110003445139 增压器垫片A1A00-1118002 Gasket 1
9 4110003445140 管夹组件G2GYA-1118270 Clamp 1
10 4110003445141 进油管焊接组件J9E00-1118240 Oil pipe 1
11 4110001194028 增压器进油管接头L3000-1118031 Nipple 1
12 4110000009034 O形圈2. 65X17YC208-B01700F O-ring 2
13 4110001058001 增压器回油管 J8000-1118340A Pipe 1
14 4110000560283 螺栓 M8×25 Q1840825TF2 Screw 2
15 4110001058074 增压器回油管垫片 M3600-1118301A Washer 1
消声器总成 Air silencer
1 4110000009025 垫片475D-1008026A Washer 1
2 4110001194033 螺栓M8X28 Q1840828TF2 Screw 6
3 4110003445003 消音器J9900-1201100 Silencer 1
4 4110000562056 排烟管喉箍总成640-1201300 Clamp 1
5 4110000562055 消声器排烟器1640H-1201200B Exhaust pipe 1
6 4110003445142 螺栓M10X60YC3-1060TF2 Screw 2
7 4110003445143 螺栓套1575-1008226 Sleeve 2
8 4110003445144 消声器支架焊件J9E00-1201050 Bracket 1
9 4110000560286 螺栓 M10X30 Q1841030TF2 Screw 2
10 4110003445145 六角法兰面锁紧螺母M10Q33010T13F2 Nut 2
散热器水管及软管总成 Water pipe assembly
1 4110001058025 螺栓A3206-1002236 Screw 12
2 4110003445146 出水管组件J8L00-130304 Water outlet pipe 1
3 4110000561279 锥形螺塞 NPT1/2 Q618B04 Plug 1
4 4110000560331 螺塞 NPT3/8 Q618B03 Plug 3
5 4110003577086 出水支管垫片B8701-1303042 Gasket 6
放水开关总成 Draining valve
1 4110000560091 操纵杆150-1305015 Link rod 1
2 4110000560326 销 3. 2X20 Q5003220 Pin 1
3 4110000560076 放水阀芯6105Q-1305014A Valve rod 1
4 4110000560075 放水阀体6105Q-1305013 Valve body 1
5 4110000560074 垫圈6105Q-1305012 Washer 1
6 4110000560073 弹簧6105Q-1305011 Spring 1
7 4110000560294 垫圈 6 Q40006 Washer 1
8 4110000560325 销 1. 6X10 Q5001610 Pin 1
