ORIGINAL SDLG LG956N WHEEL LOADER SPARE PARTS 29220009021 BLOCK FOR Travel brake system J2200-2922002023

SDLG WHEEL LOADER LG956N PARTS Travel brake system J2200-2922002023

1 29220009021 接头块 Block Y 8
2 4030000552 O形圈 O-ring Y 16
3 29220001251 制动器管接头 Nipple Y 4
4 29220020451 桥油管 Brake pipe Y 4
5 29220009011 管接头 Nipple Y 4
6 4030000055 螺塞JB1000-M22*1.5EpZn-35 Plug Y 1
7 29220020151 后桥左油管 Brake pipe Y 1
8 4011000807 螺栓GB16674-M8*12EpZn-8.8 Bolt Y 3
9 29220000821 三通管 Three-way nipple Y 1
10 29010000041 螺栓 Screw Y 2
11 29220000811 垫圈 Washer Y 10
12 4011001250 螺栓GB5783-M12*30flZnyc-8.8-480 Screw Y 4
13 4015000427 垫圈GB96.1-12flZnyc-300HV-480 Washer Y 4
14 29220019831 储气罐 Air reservoir Y 1
15 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 8
16 4011001249 螺栓GB5783-M10*30flZnyc-8.8-480 Screw Y 4
17 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 4
18 4120006350 加力泵LG22-JLB-A Air cylinder N 2
19 29220001241 加力泵接头块 Nipple Y 2
20 29220001231 加力泵管接头 Bolt Y 2
21 4030000551 O形圈 O-ring Y 4
22 4041001945 软管LGB153-202370 Hose Y 1
23 29010000031 管夹 Clamp Y 3
24 29220020111 前桥左油管 Brake pipe Y 1
25 29220011131 固定板 Anchor plate Y 1
26 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 1
27 29220009031 三通接头 Three-way nipple Y 2
28 4011001295 螺栓GB16674.1-M8*25flZnyc-8.8-480 Screw Y 6
29 29220020131 前桥右油管 Brake pipe Y 1
30 4041001232 软管LGB145-205200 Hose assembly Y 1
31 29220016661 直接头 Nipple Y 1
32 4120003758 气制动阀LY60E Brake valve Y 1
33 4120003757 制动灯开关YK209KLA Pressure switch Y 1
34 29220017601 直接头 Nipple Y 3
35 4041002476 软管LGB146-206175 Hose assembly Y 1
36 4041002424 软管LGB145-202150 Hose assembly Y 1
37 4190001839 扎丝LG13-ZS4*160 Cable tie Y 2
38 29220019881 直接头M10-M12 Nipple Y 1
39 29220009121 垫圈 Washer Y 3
40 4120000741 开关阀LG09-KGF Valve Y 1
41 4014000088 螺钉GB818-M5*16EpZn-4.8 Screw Y 2
42 29220009111 螺栓 Bolt Y 1
43 4041001043 软管LGB145-002136 Hose assembly Y 1
44 29220008451 直接头 Nipple Y 2
45 29220020871 软管 Hose assembly Y 1
46 29220020461 干燥器模块 Airer assembly N 1
47 4041001234 软管LGB146-205086 Hose assembly Y 1
48 29220018641 压块 Block Y 2
49 4011000481 螺栓GB16674-M8*30EpZn-8.8 Bolt Y 4
50 29220017701 加力泵至后桥油管 Hose Y 1
51 29220017521 钢管 Brake pipe Y 1
52 29220020171 后桥右油管 Brake pipe Y 1
