SERVO VALVE PIPING SERVO VALVE PIPING – SHANTUI SD22、SD22E 、SD22S 、SD22D 、SD22R 、SD22C BULLDOZER PART CATALOG

SERVO VALVE PIPING SERVO VALVE PIPING – SHANTUI SD22、SD22E 、SD22S 、SD22D 、SD22R 、SD22C BULLDOZER PART CATALOG

108.SERVO VALVE PIPING SERVO VALVE PIPING - SHANTUI SD22、SD22E 、SD22S 、SD22D 、SD22R 、SD22C BULLDOZER PART CATALOG

622-1 07102-20410 软管 hose 622-2
2 154-61-17150 管 tube 3
3 07042-20108 螺塞 plug 4
4 07000-03025 O 型圈 O-ring 5
5 01010-51045 螺栓 bolt 6
6 01602-21030 弹簧垫圈 washer spring 7
7 08035-02508 卡箍 clip 8
8 01011-51016 螺栓 bolt 9
9 01602-21030 弹簧垫圈 washer spring 10
10 154-61-17131 管 tube 11
11 07000-03025 O 型圈 O-ring 12
12 01010-51045 螺栓 bolt 13
13 01602-21030 弹簧垫圈 washer spring 14
14 07102-20412 软管 hose 15
15 07234-10422 弯头 elbow 16
16 07239-12009 螺帽 nut 17
17 07002-02034 O 型圈 O-ring 18
18 154-61-17140 托架 bracket 19
19 01010-51225 螺栓 bolt 20
20 01602-21236 弹簧垫圈 washer spring 21
21 08035-02508 卡箍 clip 22
22 01010-51016 螺栓 bolt 23
23 01602-21030 弹簧垫圈 washer spring 24
